Ss316L Back Pressure Regulating Valve Body Material Nickel Plated Brass Single Stage

Place of Origin : Guangdong, China (Mainland)

Brand Name : AFK

Model Number : R52

Supply Ability : 30000 Piece/Pieces per Week

Packaging Details : white box packing+export carton

MOQ : 10 - 49 Pieces

Price : Negotiable

Certification : CE

body ports : 1/4NPT Female

inlet pressure : 500, 1500, 3000psig

outlet pressure : 0-15, 0-25, 0-50, 0-100, 0-250psig

body material : ss316L, nickel plated brass, brass

Application : lab, gas bus, oil and chemical industry, test equipment

shipping way : DHL, UPS, Fedex, by sea, by air

warranty : 1 year

Port : Shenzhen

Contact Now

Product Description

R52 series stainless steel pressure regulator, stainless steel diaphragm reducing pressure constructure, Applicable for Lab, pharmacy and chemistry industry etc.

SPECIFICATIONS FOR R52 pressure regulator

Max. inlet pressure	500, 1500, 3000psig
outlet pressure	0-15,0-25,0-50,0-100,0-250psig
safety testing pressure	1.5times max. inlet pressure
applicable temperature	-10 ℉+165℉ (-23℃+74℃)
leakage rate	foam test
Cv	0.06

Main parts of material
body	316L
bonnet	316L
seat	PCTFE
spring	316L
stem	316L
o-ring	viton
stainer	316L(10um)

Main Features

1) piston reducing pressure structure.

2) body ports:1/4NPT (F)

3) set stainer inside.

4) using panel mouting or wall mounting

Ss316L Back Pressure Regulating Valve Body Material Nickel Plated Brass Single Stage
