| Material List |
| 1 | Body | SS316L, brass, nickel plated brass ( Weigh :0.9kg) |
| 2 | Cover | SS316L, brass, nickel plated brass |
| 3 | Diaphragm | SS316L |
| 4 | Strainer | SS316L(10um) |
| 5 | Valve Seat | PCTFE,PTFE,Vespel |
| 6 | Spring | SS316L |
| 7 | Plunger Valve Core | SS316L |
| Technical Data |
| 1 | Maximun Input Pressure | 500,3000 psig |
| 2 | Output Pressure Range | 0~25, 0~50, 0~100, 0~250, 0~500 psig |
| 3 | Safety Testing Pressure | 1.5 times of maximum input pressure |
| 4 | Working Temperature | -40°F~ +165°F (-40°C~ +74°C ) |
| 5 | Leakage Rate | 2×10-8 atm cc/sec He |
| 6 | CV Value | 0.08 |
| R11 | L | B | D | F | G | 00 | 00 | P |
| Item | Body Materia | Body Hole | Inlet pressure | Outlet pressure | Pressure gauge | Inlet size | Outlet size | mark |
| R11 | L:316 | A | D:3000 psi | F:0-500 psi | G:MPa gauge | 00:1/4 " NPT (F) | 00: 1/4 " NPT(F) | P:Panel mounting |
| | B:Brass | B | E:2200 psi | G:0-250 psi | | 01:1/4 " NPT (M) | 01: 1/4 " NPT(M) | N:Needle valve |
| | | D | F:500 psi | l:0-100 psi | P:Psig/bar gauge | 23: CGA330 | 10:1/8 " OD | N:Needle valve |
| | | G | | K:0-50 psi | | 24: CGA350 | 11:1/4 " OD | D:Diaphragm valve |
| | | J | | L:0-25 psi | W:No gauge | 28: CGA660 | 12:3/8 " OD | |
| | | M | | | | 28: CGA660 | 15:6mm OD | |
| | | | | | | 30: CGA590 | 16:8mm OD | |
| | | | | | | 52: G5/8 "-RH(F) | | |
| | | | | | | 63: W21.8-14H(F) | | |
| | | | | | | 64: W21.8-14LH(F) | | |
FAQ
1. who are we?
We are based in Guangdong, China, start from 2011,sell to Southeast Asia(20.00%),Africa(20.00%),Eastern Asia(10.00%),Mid East(10.00%),Domestic Market(5.00%),South Asia(5.00%),Northern Europe(5.00%),Central America(5.00%),Western Europe(5.00%),South America(5.00%),Eastern Europe(5.00%),North America(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
pressure regulator,Tube fittings,solenoid valve,Needle valve,check valve
4. why should you buy from us not from other suppliers?
We have a couple of years with professional engineers and dedicated technicians.can provide security products for you
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese
